K12.2 | |
LF傳感器 | 12英寸(305毫米),錐形 |
HF傳感器 | 1.4英寸(35.6毫米)鈦膜壓縮驅動器 |
頻率響應(-6 dB) | 50 Hz - 20 kHz |
頻率範圍(-10 dB) | 45 Hz - 20 kHz |
標稱覆蓋角度 | 75°Axisymetric |
最大額定SPL 1 | 132 dB @ 1 M,峰值126 dB @ 1 M,連續 |
放大器 | 峰值:1800 W(LF),225 W(HF) |
控制 | Power 3 x Level Rotary encoder (push) 2 x selection buttons |
連接器 | 2 x locking XLR/F ¼⁻ᶦⁿᶜʰ combo (Mic/Line Input and Hi-Z/Line Input 1 x 3.5 mm TRS (Stereo Input) 2 x XLR/M (Loop-thru Output) 1 x XLR/M (Mix Output) 1 x locking IEC power connector |
指標 | Monochrome LCD Display 1.75-inch x 1-inch (45 mm x 25.4 mm) 2 x Power LED (front and rear) 3 x Input Signal LED Input A Mic selected LED Input B Hi-Z selected LED Limiter active LED |
交流電源輸入 | 通用電源100 - 240 VAC,50 - 60 Hz |
交流電耗電1/8電源2 | 100 VAC,2.1 A / 120 VAC,1.9 A / 240 VAC,1.1 A. |
尺寸(HxWxD) | 23.7 x 14 x 13.8 in 602 x 356 x 350 mm |
淨重 | 17.7公斤(39磅) |
